Zohar Plus front view

Designed for

Wider medium-format coverage.

  • Broader upper- or lower-body sessions
  • Premium home wellness rooms
  • Spas and flexible professional setups
LEDs300
Dimensions880 × 276 × 71 mm34.6 × 10.87 × 2.79 in
Weight11.8 kg / 26 lb
Wavelengths630 · 660 · 810 · 830 · 850 nm

What’s included

Ready for a considered setup.

  • Core / Plus Wall / Door Mount Kit
  • Protective eyewear
  • Power cables
  • User manual
  • Remote control for power
  • 3-year warranty

Recommended placement

Lightweight Electric Stand — recommended pairing

Plus Acrylic Base$239Lightweight Stand$379Lightweight Electric Stand$799Electric Stand$1,249Wall / Door Mount KitIncluded

Certified quality

Trusted performance.

FDA Registered, with ISO, RoHS, MSDS, CE and FCC documentation represented across the Zohar Series.

FDA, ISO, RoHS, MSDS, CE and FCC quality and compliance marks

Modular by design

Connect it with any other Zohar model.

Every Zohar panel can become part of a larger setup. Expand coverage later without replacing the panel you begin with.

Zohar Plus+Additional Zohar panel

Technical specifications

Details, when you want them.

The home experience stays simple. The full specifications remain available here for informed comparison.

View original specification sheet →
Size, power and construction
Frame
Aluminum alloy
Input voltage
100–240 VAC, 50/60 Hz
Rated power
1500 W
Power consumption
390 W
Dimensions
880 × 276 × 71 mm · 34.6 × 10.87 × 2.79 in
Weight
11.8 kg / 26 lb
Light system
LED quantity
300
Five wavelengths
630 / 660 / 810 / 830 / 850 nm
LED distribution
30 / 120 / 15 / 30 / 105
Lens beam angle
30°
Irradiance
160 / 151 / 130 / 113 mW/cm² at 6 / 12 / 18 / 24 in
EMF
0 μT at 2 in
Flicker
Flicker-free
LED lifespan
100,000 hours
Controls and modes
Control
Touch controls, preset modes and wireless multi-panel control support
Timer
5 / 10 / 15 / 20 / 25 / 30 minutes or adjustable 0–30 minutes
Dimmer
20 / 40 / 60 / 80 / 100% or adjustable 0–100%
Pulse modes
10 / 40 / 73 / 146 / 293 / 587 Hz or adjustable 0–10,000 Hz

Warranty

3 years included. Upgrade to 5.

Every panel includes three years of coverage beginning when the package is received. Extend it to five years with the optional model-specific upgrade.

Upgrade to 5 years

$79View Warranty Information

Zohar Plus

Ready to complete your setup?

We will confirm compatibility, delivery details and the best stand or mount for your room.

Contact to Complete Purchase
